Why a Homemade Hay Rack Is Worth the Afternoon

Anyone who keeps horses, ponies, goats or sheep knows the depressing sight of a fresh bale of hay being trodden into the bedding within an hour. Hay eaten from the floor becomes mixed with droppings, urine and mud, and most animals will simply refuse the soiled portions. Across a winter that waste adds up to a serious amount of money, particularly with small bales costing what they do now.

A simple timber rack solves most of that. It lifts feed clear of the ground, keeps it dry and lets the animal pull out mouthfuls at a natural pace rather than gorging from a pile. Built properly from treated timber, a rack will outlast several hay nets and costs a fraction of a ready-made steel version. It is also a genuinely satisfying project for a wet weekend, needing no more than basic tools and a trip to the local farm or timber merchant.

Choosing the Right Materials

The rack needs to stand up to weight, damp and chewing, so buy timber accordingly. Pressure-treated sawn timber is the sensible choice — it resists rot and does not need painting, though a coat of animal-safe wood preserver will extend its life further. Avoid anything that has been treated with creosote or similar products not suitable around livestock.

• Frame: 47mm x 75mm treated sawn timber for the back rail, sides and the uprights that carry the load.
• Feeding bars: 45mm x 45mm or 50mm x 50mm treated timber, or smooth round rails if you have them.
• Base tray: exterior-grade plywood, 18mm thick, drilled with a few drainage holes.
• Fixings: 8mm galvanised coach bolts for the main joints, 80mm exterior wood screws elsewhere, and a weatherproof wood adhesive in the joints.
• Tools: a saw, cordless drill, spade bit, tape measure, square, clamps and sandpaper. A power sander saves time on the bar edges.

Galvanised fixings matter more than people expect. Standard screws rust through within a couple of seasons in a damp stable and leave a rack that wobbles dangerously.

Sizing It for Your Animal

Get the dimensions right and the rack will be safe and comfortable; get them wrong and you will be dealing with trapped hooves or a horse that refuses to use it. As a rough guide for a horse of around 15 hands, make the rack roughly 700mm wide, 350mm from front to back, and set the bottom edge of the feeding bars about 800mm above the floor. Ponies need everything lower — around 600mm works well — and smaller native breeds will want a narrower width so they are not reaching awkwardly.

The critical measurement is the gap between the feeding bars. Aim for 60mm to 75mm. This is wide enough for a horse to pull hay through comfortably but too narrow for a hoof or a muzzle to become wedged. Never leave gaps above 90mm, and never mix wide and narrow spacing in the same rack. Round off every cut edge with sandpaper until it feels smooth against the back of your hand — a splinter in a horse's lip or nostril is an unpleasant problem to treat.

Building the Frame

Cut the two side panels first: each one is a triangle or trapezoid, with a vertical back edge, a horizontal base and a sloping front that carries the feeding bars. Keep the sides identical by clamping them together and cutting both at once. Cut the back rail and the base to the width of the rack, then assemble the three-sided box with glue and coach bolts through pre-drilled holes.

Fit the plywood base into the bottom, screwing it down from underneath, then drill half a dozen 10mm drainage holes so rain, spilled water and dust do not sit in the tray. Now fix the feeding bars across the sloping front, spacing them evenly and checking your gap measurement with an offcut before driving every screw home. Add a top rail across the front to brace the bars and finish the job with a good sanding of every surface the animal will touch.

Smallholders keeping goats or sheep can use exactly the same design, just narrower and lower, with the bars set at 50mm. A rack mounted on legs rather than a wall also works well in a field shelter and can be moved with the flock.

Fitting It Safely in the Stable

Position the rack in a corner, well away from the door, and never directly above a water bucket or feed bowl where dropped hay will spoil it. A full rack with a small bale in it can weigh 20kg or more, so the wall fixings must be serious. If the stable wall is timber-framed, drive 100mm coach screws straight into the studs. For brick or block, use proper masonry frame fixings of at least 8mm and drill to the correct depth.

Check the level before tightening anything fully. A rack that sits at an angle will shed hay to one side and encourage the animal to pull at an awkward twist. Once mounted, push down hard on the base and give it a good shake — if there is any movement at all, add another fixing before the horse gets near it.

Using and Maintaining the Rack

Fill little and often rather than cramming the rack full. Tempting as it is to top it up for the day, a tightly packed rack makes hay hard to pull out and animals will drag it in frustration, defeating the purpose. Shake the hay loose as you load it so dust falls away, and clean out stale leftovers each morning.

Give the rack a quick inspection every month or so. Look for loose screws, hairline splits in the bars and any chewing damage along the top rail. Sand down rough patches immediately and replace any bar that has cracked rather than patching it. Treated timber in a dry stable should give you eight to ten years of service, and a rack that is checked regularly will quietly save you a bale a week through the winter.
