Why Gateways and Troughs Turn to Mud

Every wet winter, the same spots on a smallholding become a quagmire: the gateway where animals crowd, and the ring around the trough where they stand to drink. These are high-traffic areas with no chance for grass to recover. Each hoofprint compresses the soil, breaks the roots and creates a shallow pan that holds water. Once the surface is broken, rain fills the hollows and hooves churn them deeper. The result is poached ground that never dries out.

Mud around the trough is more than an eyesore. It can cause mud fever, thrush and abscesses in horses, and foot rot in sheep and cattle. Animals may drink less if the approach is deep and slippery, and feed dropped in mud is wasted. A churned gateway is also dangerous underfoot for you. The fix is a combination of hard standing, drainage and regular movement of feeders and troughs.

Install Hard Standing Where It Counts

Hard standing is the most effective solution. You do not need to concrete the whole field. Focus on a 3m x 3m pad inside and outside each gateway, and a 2m apron around every trough. Dig out 150mm of soft soil, lay a geotextile membrane, then top with 100–150mm of compacted MOT Type 1 stone. The membrane stops the stone sinking into the mud. Compact it in layers and add a grit or rubber mat finish if you want a kinder surface for hooves. Permeable grass paving or block paving works well on sloping gateways.

• Gateways: 3m x 3m pads inside and out.
• Troughs: 2m apron with a slight fall of about 1:80.
• Base: geotextile membrane plus 100–150mm compacted MOT Type 1.

Trough aprons can be simpler. A concrete pad is ideal, but a well-laid stone pad will do. If the trough is in the middle of a field, move it to a corner or beside a gateway where hard standing already exists. Avoid loose bark or woodchip as a permanent base; it rots, turns spongy and harbours bacteria. Use it only for temporary paths or around feeders you move often.

Divert Run-Off Before It Reaches the Gate

Water from uphill will always find the lowest point, usually your gateway. Cut it off before it gets there. A shallow cut-off ditch, 300mm deep and 600mm wide, along the upper side of the gateway can intercept surface water and lead it to a hedge or soakaway. Line it with gravel if erosion is likely. For smaller volumes, a French drain — a gravel-filled trench with a perforated pipe — will take water away underground. Give any pipe a fall of at least 1:100 and make sure it exits somewhere safe.

Check the trough itself. An overflowing ball valve creates a permanent bog. Test it regularly and fit an overflow pipe that carries surplus water away from the standing area. If a roof is nearby, guttering and downpipes should discharge into a water butt or piped drain, not onto the ground where animals stand. Keep clean rainwater separate from dirty water, and check local rules if run-off could reach a watercourse.

Move Troughs, Feeders and Hay Stations

Even with hard standing, animals will congregate. Spread the load by moving the furniture. Mobile troughs on skids or small wheels can be shifted every week or two. Hay rings and feeders should be moved before the ground is poached, not after. Move them when the grass cover is half worn away or when you see the first deep hoofprints. In wet weather, that might mean every few days. Feed on a hard standing pad if possible, or rotate between several pads. Hay nets hung in different places along a fence line also reduce hoof concentration, as long as you move the net before the spot turns to slop.

If you use a ring feeder in a field, place it on a pallet or a temporary stone pad that you can move. Do not leave it in the same place for weeks. For ponies and smallholders with a few animals, three or four feeding stations rotated regularly work well. The same applies to salt licks and mineral blocks. Small changes make a big difference to the amount of mud you manage.

Control Traffic, Rest Ground and Repair Quickly

Think about how animals move. If every horse or sheep must pass through one gateway to reach water, that gateway will never recover. Add a second gateway or a temporary electric fence lane to split traffic. Strip grazing with electric tape forces animals to eat across a paddock rather than trample a small area. Move the fence daily or every few days, and keep the trough at the edge of the strip. In very wet conditions, sacrifice one small woodchip or stone pad rather than let the whole field be churned. Rest is essential. Keep a sacrifice paddock for the wettest weeks, and bring animals in earlier or turn them out later when the ground is less saturated.

Walk your gateways and troughs every day or two. Pick debris from the trough and check the overflow. Fill small poached patches with stone or woodchip, not soil, which will turn back to mud. Do not harrow a wet field; wait for a dry spell, then roll or harrow lightly. In spring, overseed bare patches with a hardy grass mix and keep animals off until it establishes. A little attention now saves hours of wheelbarrow work later and keeps your animals sound, clean and content through the wettest months.
